GOKU GM10 Nano V3 GPS w/compass
35 people are viewing this product right now
🔥 8 items sold in last 3 hours
Brand:
The Flywoo GOKU GM10 Nano V3 GPS with Compass is an ultra-compact GNSS module designed for lightweight FPV drones. Weighing just 2.6g and measuring 12mm x 17mm x 5mm, it offers high-precision navigation with support for GPS, GLONASS, Galileo, BeiDou, QZSS, and SBAS. Equipped with a 72-channel M10050 chipset, it ensures rapid satellite acquisition and reliable performance. Ideal for both analog and digital FPV systems, this module features a plug-and-play setup with a 4-pin connector, eliminating the need for soldering.
₹2,094.29
-
Chipset: M10050 (10th Generation)
-
Dimensions: 12mm x 17mm x 5mm
-
Weight: 2.6g
-
Connector: 4-pin pad (no soldering required)
-
Supported GNSS Systems: GPS, GLONASS, Galileo, BeiDou, QZSS, and SBAS
-
Channels: 72
-
Sensitivity: Tracking: -162dBm; Reacquisition: -160dBm
-
Data Protocols: BF4.3.X (UBLOX) / BF4.2.X (NMEA)
-
Output Frequency: 1Hz–10Hz (default 10Hz)
-
Power Supply: 3.3–5V DC
-
Operating Temperature: -40°C to +85°C
-
Storage Temperature: -40°C to +105°C
-
Includes: 1x GM10 Nano V3 GPS with Compass, 1x 100mm Cable, 1x Copper Foil
